Surface Mounted Downlight, Nimbus Modul Q 100 ON-XD, 230 V - 833.69.117
Light

Surface Mounted Downlight, Nimbus Modul Q 100 ON-XD, 230 V - 833.69.117

HAFELE

Download Product Files

Surface Mounted Downlight, Nimbus Modul Q 100 ON-XD, 230 V - 833.69.117 by Hafele — A modern lighting solution for your spaces.

Properties

Product Code: 833.69.117
Category: Light

Material Properties

Used Material:
Acrylic glas
Durability:
>50,000 h

Product Attribute Symbols
Dimensions

Length (cm): 20
Width (cm): No Information
Height (cm): No Information
Volume (cm³): No Information

Assembly and Installation Instructions

Assembly: Please refer to the installation guide.
Assembly Tools: Please refer to the installation guide.
Assembly Instructions: Please refer to the installation guide.
Professional Help: Authorized service support can be obtained if necessary.

Care and Cleaning Instructions

Cleaning Instructions: Wipe with a damp soft cloth, do not use abrasive cleaners.
Care Instructions: Check regularly to ensure no mechanical damage has occurred.
Recommended Cleaning Materials: Soft cloth or sponge.

Safety and Quality Documents
  • ISO_9001_TR
  • 833.69.117_Safety notes
  • ISO_27001_TR
  • ISO_9001_ENG
  • Güvenlik Notları--Security Notes
  • ISO_27001_ENG
Images
Pricing and Payment Conditions

Pricing Policy: Please contact the sales team.
Payment Options: Credit card, bank transfer and cash on delivery options are available.
Delivery Period: Please contact the sales team.
Minimum Order Quantity: Please contact the sales team.

Warranty and Servicing Information

Warranty Period: 2 years
Warranty Coverage: Covered against manufacturing defects.
Service Contact : Please contact the sales team.

References

No image

The Surface Mounted Downlight, Nimbus Modul Q 100 ON-XD, 230 V - 833.69.117 by Hafele represents a refined fusion of quality and functionality. With its modern design and acrylic glass material, this lighting solution features 100 LEDs that provide high illumination power. Offering 2,260 lm of luminous flux while consuming only 21.80 W, it ensures energy efficiency.

Designed for longevity, it boasts a lifetime of L80/B10 exceeding 50,000 hours. With a color rendering index Ra >90 and R9 >50, it accurately reflects true colors. Rated at IP20, it is safe for indoor use. Installation is straightforward, allowing for screw fixing with a magnetic mounting plate, and it can be directly mounted with a drilling distance of 79 mm.



The Nimbus Modul Q 100 ON-XD by Hafele combines modern design and high performance, making it an excellent choice for your indoor lighting needs.
